UCR 1325A

Widely used for engraving, membrane door designing, acrylic carving, decorative panels, wave boards, grill boards etc.

MODEL UCR 1325A UCR 1325B
X, Y working area 1300 x 2500mm 1300 x 2500mm
Z working area 200mm 200mm
Table size 1440 x 3040mm 1440 x 3040mm
Lathe structure Welded steel structure Welded steel structure
X, Y structure Rack and pinion transmission Rack and pinion transmission
Z structure 0 180mm 90mm
Diameter of scoring saw blade shaft Ball screw transmission Ball screw transmission
Max. Idling speed 35m/min 35m/min
Spindle 4.5kw 4.5kw
Spindle speed 0-24000r/min 0-24000r/min
Working mode Stepper Stepper
Command G code, HPGL, Uoo. mmg; plt G code, HPGL, Uoo. mmg; plt
Operating system DSP with USB interface DSP with USB interface
Diameter of cutter 3.175 - 12.7 mm 3.175 - 12.7 mm
Cooling mode Water-cooling Water-cooling
Dust collect function Yes Yes
Work holding By clamp By suction

Salient Features


This CNC Router, configured with high quality spare parts. It can be used to cut or engrave on plastic, acrylic, composite panel, wood, MDF, aluminum, copper, etc., widely used in Wadvertising and woodworking industries. wood working, like cutting and engraving ith hard steel structure, is fit for hard on Rosewood for furniture, indoor holding decoratioway n. Aand nd wdust ith collector the Vac , uuthe m machine is qualified for mass-producing of furniture. We use top quality components for the machines, like HSD spindle, Delta Inverter, Becker Vacuum pump, Hiwin linear and so on, to keep the machine in the best condition even after many years working.

  • The machines' body is strong, rigid, high precision, reliable and durable.
  • Imported high-precision ball screw gap, smooth movement, to ensure that the machine tools high-precision.
  • Using well-known domestic brands of water-cooled brushless spindle, low noise, strong cutting ability, to ensure the long time working.
  • High-performance driven motor to ensure that the low noise, strong cutting ability, to ensure the long time working. machines high speed and accuracy.
  • Designer perfectly, select the best machine accessories, to minimize the failure rate preferred.
